Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal
Z Type Dam Gate Seal

Z Type Dam Gate Seal

Price 1800.0 INR/ Meter

MOQ : 1 Meter

Z Type Dam Gate Seal Specification

  • Hardness
  • 655 Shore A
  • Rubber Type
  • Natural Rubber, EPDM, SBR, Nitrile
  • Compression Ratio
  • Up to 30%
  • Tensile Strength
  • Minimum 12 MPa
  • Natural Rubber
  • Available in Natural Rubber (NR), EPDM, and SBR
  • Thermal Conductivity
  • Low (non-conductive)
  • Temperature Resistance
  • -40C to +110C
  • Weight
  • Varies as per dimension and length
  • Density
  • 1.15 Gram per cubic centimeter(g/cm3)
  • Part Type
  • Profile Seal
  • Usage & Applications
  • Dam gate sealing, spillway gates, stop log gates, radial gates, penstock gates, water retaining structures
  • Color
  • Black
  • Feature
  • Leak-proof, flexible, long service life, weather-resistant
  • Width
  • 75 mm to 300 mm (customizable)
  • Water Absorption
  • < 1% by weight
  • Flame Resistance Level
  • Standard (option for flame-retardant grades on request)
  • Surface Finish
  • Smooth or textured as specified
  • Nitrogen Content (%)
  • 0.5%
  • Diameter
  • As per drawing/custom size
  • Material
  • High-grade synthetic/natural rubber (NR/EPDM/SBR/Nitrile)
  • Product Type
  • Z Type Dam Gate Seal
  • Volatile Matter (%)
  • < 1%
  • Components
  • Single or multi-component rubber gasket
  • Style
  • Z-Type extruded or molded rubber seal
  • Length
  • Up to 15 meters in single length or as required
  • Ash %
  • 2%
  • Size
  • Custom sizes available as per client specification
  • Tolerance
  • 2 mm
  • Resistance level
  • High resistance to abrasion, water, UV, and ozone
  • Thickness
  • 10 mm to 60 mm (as per order)
  • Ozone Resistance
  • Excellent, as per ASTM D1171
  • Manufacturing Process
  • Extruded/Molded
  • Standards
  • IS 15466, ASTM D2000
  • Service Life
  • Designed for 10+ years under normal operating conditions
  • Weather Resistance
  • Superior resistance against sunlight and atmospheric conditions
  • Storage Recommendations
  • Store in a cool, dry place away from direct sunlight
  • Chemical Resistance
  • Good resistance to salts and mild acids
  • Installation Method
  • Bolted/Clamped onto dam gate structure
  • Elongation at Break
  • 300% minimum



About Z Type Dam Gate Seal



Explore the meritorious Z Type Dam Gate Seal, engineered for dominant performance in water retaining structures and dam gates. Crafted using a superior extruded or molded manufacturing process, this profile seal accommodates widths from 75 mm to 300 mm and custom sizes. It boasts a minimum elongation at break of 300% and a high tensile strength of 12 MPa, ensuring valorous leak-proof operation. With excellent resistance to weather, ozone, chemicals, and UV, this seal is designed for longevity, meeting IS 15466 and ASTM D2000 standards. Order now for clearance prices and discover superior reliability.

Competitive Advantages and Features of Z Type Dam Gate Seal

Z Type Dam Gate Seal delivers exceptional competitive advantages, such as its flexible and leak-proof structure, valorous abrasion and weather resistance, and a long service life exceeding 10 years. Its robust design, adaptable to custom dimensions and finishes, ensures meritorious performance across dam gates, penstock gates, and spillway gates. The seal offers special features like a high compression ratio, low water absorption, and multiple rubber material options, thereby catering to diverse installation needs with dominant reliability.


Supply Ability, Packaging, and Export Markets for Z Type Dam Gate Seal

We ensure timely dispatching of Z Type Dam Gate Seals with a high supply capacity for bulk orders. Packaging is meticulously handled, using robust materials to prevent transit damage and preserve integrity. List price options accommodate dealers, traders, and wholesalers alike. Our main export markets span India and global regions, with efficient logistic solutions to guarantee seamless delivery. Reliable supply, strategic packaging, and competitive pricing make us a trusted partner for dam infrastructure projects worldwide.


FAQ's of Z Type Dam Gate Seal:


Q: How is the Z Type Dam Gate Seal installed?

A: The Z Type Dam Gate Seal is installed by bolting or clamping onto the dam gate structure, ensuring a secure and leak-proof fit for various dam applications.

Q: What materials are used in the manufacturing process of this seal?

A: This seal is manufactured using high-grade synthetic and natural rubber options, including NR, EPDM, SBR, and nitrile to provide excellent resilience and durability.

Q: What are the benefits of using the Z Type Dam Gate Seal in water retaining structures?

A: The primary benefits include excellent leak-proofing, superior resistance to ozone, UV, and abrasion, extended lifespan, and the ability to withstand harsh atmospheric and chemical exposures.

Q: Where can custom sizes of this dam gate seal be ordered?

A: Custom sizes and lengths of Z Type Dam Gate Seals can be ordered directly from authorized manufacturers, dealers, and suppliers. Specifications must be provided at the time of order.

Q: What competitive advantages does this seal offer over standard alternatives?

A: It provides a higher elongation at break, a minimum tensile strength of 12 MPa, enhanced ozone and weather resistance, and flexibility in sizing, ensuring superior performance and longevity.

Tell us about your requirement
product

Price:

Quantity
Select Unit

  • 50
  • 100
  • 200
  • 250
  • 500
  • 1000+
Additional detail
Mobile number

Email

More Products in Dam Gate Seal Category

Bottom Dam Gate Seal

Bottom Dam Gate Seal

Price 650.0 INR / Meter

Minimum Order Quantity : 1 Meter

Usage & Applications : Dam gate sealing, water control structures, hydropower plants, flood barriers, irrigation projects

Color : Black

Surface Finish : Smooth or textured

Material : EPDM/Natural Rubber/Nitrile/Neoprene

PTFE Calladed Dam Gate Seal

PTFE Calladed Dam Gate Seal

Price 200.0 INR

Minimum Order Quantity : 1

Usage & Applications : Suitable for dam gate sealing to prevent water leakage and enhance gate performance

Color : White

Surface Finish : Smooth, low friction

Material : PTFE (Polytetrafluoroethylene)

Deep Galvanized  Drainage Spout
