Rubber Expansion Joint Bellow

Get a Price/Quote

Rubber Expansion Joint Bellow Specification

Cover
EPDM Rubber

Connection Type
Flanged

Medium
Water, Oil, Mild Chemicals

Shape
Round Bellow

Reinforcement
Strong Textile and Steel Wire

Hardness
63-65 Shore A

Material
High Grade Rubber

Temperature
-30C to +120C

Pressure
up to 16 bar

Inside Diameter
80 mm

Outside Diameter
100 mm

Movement Axial Elongation
6 mm

Movement Angular
8°

Movement Axial Compression
18 mm

Weight
approx. 3.5 kg

Application
Piping System, HVAC, Industrial Usage

Movement Lateral
12 mm

Standard
IS:5382/BS EN 681-1

Packaging Type
Corrugated Box

End Connection
Drilled Flange as per IS:1538/ANSI/DIN

Flange Material
Mild Steel

Color
Black

Leakage Test Pressure
24 bar

About Rubber Expansion Joint Bellow

Don't miss this Last Chance to order our Best-selling Rubber Expansion Joint Bellow with Flange! This first-string component is crafted with high grade rubber and reinforced with strong textile and steel wire, making it a gorgeous choice for demanding piping systems. Designed to handle axial compression, elongation, lateral, and angular movements, it meets the crowning standards of IS:5382/BS EN 681-1. Suitable for HVAC, industrial, and piping applications, it withstands temperatures from -30C to +120C and pressures up to 16 bar. Buy Online from India's trusted manufacturer and enjoy assured quality, quick shipping, and robust packaging.

Versatile Applications and Excellent Features

The Rubber Expansion Joint Bellow finds wide usage across water, oil, and mild chemical pipelines in industries, power plants, HVAC, and plumbing works. Its strong EPDM cover and flexible design help reduce vibration, absorb movement, and protect pipelines from sudden shocks. Used as a vital connector in industrial and commercial infrastructure, its flanged ends and robust build ensure a leak-proof, durable performance across numerous demanding operational environments.

Payment Terms, Export Destinations, and Delivery Logistics

We offer flexible payment solutions for your convenience. Our main export markets include Southeast Asia, Africa, the Middle East, and Europe. Upon your confirmed order, the product is shipped swiftly, ensuring timely arrival thanks to our streamlined logistics and reliable delivery partners. Standard delivery time is 3-7 business days within India, while international delivery timelines vary based on location and shipping method. Track your shipment from dispatch to arrival for peace of mind.

FAQ's of Rubber Expansion Joint Bellow:

Q: How is the Rubber Expansion Joint Bellow installed in piping systems?

A: The bellow is installed using its drilled flange ends, matching standard IS:1538/ANSI/DIN specifications, allowing easy integration with existing pipelines in HVAC and industrial systems.

Q: What benefits does the Rubber Expansion Joint Bellow provide for industrial applications?

A: It absorbs vibrations, allows for various types of movement, and protects the pipeline from thermal expansion, contraction, and mechanical stress, enhancing the system's longevity.

Q: Where can the Rubber Expansion Joint Bellow be effectively used?

A: It is highly effective in water, oil, and mild chemical pipelines, including sectors like HVAC, plumbing, power plants, and general industrial applications.

Q: When will my order be shipped and how long does delivery take?

A: Orders are shipped within 1-3 business days after payment. Delivery typically takes 3-7 business days within India, while international shipping depends on your location.

Q: What is the process for online purchasing and logistics tracking?

A: Easy buy online process: select your product, complete payment, and get shipment details. Track your order via provided logistics information until arrival at your destination.
