Industrial Discharge Rubber Hose

Price 1950 INR/ Meter

Get a Price/Quote

Industrial Discharge Rubber Hose Specification

Shape
Round

Hardness
60 to 65 Shore A

Usage
Fly Ash Rubber Hose, tank, truck, Bulker loading / unloading or in-plant transfer of dry bulk cement, sand, lime, slurry etc., suction or discharge of abrasive materials. Construction: Lining : Uniform seamless tube of natural and synthetic blend rubber compound with excellent resistance to abrasion. Reinforcement : Reinforcement of rubber impregnated woven textile applied on bias at approx.45 degree angle combination with galvanized steel wire Cover : Corrugated/plain cloth marked outer cover made from natural rubber compound with excellent weather and abrasion resistant. End Connections : Each Hose Length has soft ends for clamping or can be supplied with different type of nipples, flanges or fittings as per requirement. Cover: W.P. of 1.0 Mpa & Min. B.P. of 3.0Mpa. W.P. of 1.5 Mpa & Min. B.P. of 4.5Mpa . As Per IS: 13071-1991 Specification Construction :

Material
Rubber

Size
100mm ID to 400mm ID

Temperature
70 Deg C. to 100 Deg C Max Celsius (oC)

Product Type
Vacuum Hose Pipe

Pressure
10 Bar

Color
Black

Length
1-15 Meter (m)

Warranty
1 years

Industrial Discharge Rubber Hose Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash in Advance (CID)

Supply Ability
5 Per Day

Delivery Time
7 Days

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About Industrial Discharge Rubber Hose

Fly Ash Rubber Hose, tank, truck, Bulker loading / unloading or in-plant transfer of dry bulk cement, sand, lime, slurry etc., suction or discharge of abrasive materials.

Construction:

Lining : Uniform seamless tube of natural and synthetic blend rubber compound with excellent resistance to abrasion.

Reinforcement : Reinforcement of rubber impregnated woven textile applied on bias at approx.45 degree angle combination with galvanized steel wire

Cover : Corrugated/plain cloth marked outer cover made from natural rubber compound with excellent weather and abrasion resistant.

End Connections : Each Hose Length has soft ends for clamping or can be supplied with different type of nipples, flanges or fittings as per requirement.

Cover: W.P. of 1.0 Mpa & Min. B.P. of 3.0Mpa.

W.P. of 1.5 Mpa & Min. B.P. of 4.5Mpa .

As Per IS: 13071-1991 Specification

Construction :

Durable Construction for Demanding Environments

The hose features a seamless blend of natural and synthetic rubber lining, reinforced with woven textile and galvanized steel wire. Its corrugated or plain weather-resistant cover safeguards against abrasions, ensuring sustained performance in challenging industrial settings. Designed to meet IS: 13071-1991 standards, it offers reliable operation for bulk material transfers.

Versatile Application Across Industries

Whether used for suction or discharge, this hose excels in transferring dry bulk cement, fly ash, sand, lime, and slurry. It's an essential component for tankers, bulker loading and unloading, and in-plant processing. Available in various sizes and with multiple end connection options, it can easily be integrated into diverse systems.

Optimal Performance and Customization

Operating at a working pressure of up to 1.5 MPa with a minimum burst pressure of 4.5 MPa, this hose ensures safety and efficiency in high-pressure conditions. The soft ends enable easy installation, while customized fittings such as nipples and flanges accommodate specific operational needs. Its high hardness rating and resistance to temperatures up to 100C deliver lasting value.

FAQ's of Industrial Discharge Rubber Hose:

Q: How can the Industrial Discharge Rubber Hose be installed for different applications?

A: The hose features soft ends for clamping as standard, but can also be supplied with a variety of fittings such as nipples and flanges. This allows easy attachment to tankers, bulkers, or in-plant transfer systems. Simply choose the required end connection based on your operational needs.

Q: What materials can this rubber hose safely handle?

A: Designed for versatility, the hose is suitable for transferring dry bulk cement, fly ash, sand, lime, slurry, and various abrasive substances. Its abrasion-resistant lining ensures long-lasting performance even when handling harsh materials.

Q: When is maintenance typically required for these hoses?

A: Routine inspection is advised to check for wear or damage, especially after extended use with abrasive materials. While the robust construction minimizes maintenance frequency, it is prudent to monitor hose integrity to ensure safety and efficiency throughout its 1-year warranty period.

Q: Where can the Industrial Discharge Rubber Hose be used?

A: This hose is ideal for use in cement plants, construction sites, industrial loading/unloading docks, and in-plant transfers across India. Its adaptable length and diameter options make it suitable for tankers, trucks, bulkers, and fixed installations.

Q: What is the benefit of the reinforced construction used in this hose?

A: The combination of rubber-impregnated textile reinforcement at a 45-degree bias angle and galvanized steel wire ensures exceptional durability and resistance to both internal and external pressures. This enhances safety and prolongs hose lifespan.

Q: How does the hose perform under various temperatures and pressures?

A: The hose is engineered to withstand working pressures up to 1.5 MPa and burst pressures up to 4.5 MPa, handling temperatures from 70C to 100C. This ensures reliable performance under demanding industrial conditions.
