Price 300 INR/ Meter

Strip Seal Specification

  • Style
  • Compression Seal
  • Part Type
  • Expansion Joint Strip
  • Thickness
  • 8 12 mm
  • Flame Resistance Level
  • Standard ASTM compliant
  • Feature
  • Designed for bridge expansion joints
  • Weight
  • Approx. 1.25 kg/m (varies by size)
  • Compression Ratio
  • Can accommodate 25-40% joint movement
  • Tensile Strength
  • >13 MPa
  • Natural Rubber
  • Natural & synthetic rubber blends
  • Usage & Applications
  • Bridge expansion joint sealing
  • Diameter
  • N/A (Rectangular profile)
  • Thermal Conductivity
  • Low
  • Color
  • Black
  • Width
  • 70 mm (standard, customizable options available)
  • Resistance level
  • High to deformation, ozone, and weathering
  • Rubber Type
  • EPDM/Natural rubber blend
  • Volatile Matter (%)
  • Standard Industrial Grade, exact on request
  • Size
  • Custom lengths and sizes as required
  • Length
  • Available in rolls or cut to length as specified
  • Water Absorption
  • <1% (nearly hydrophobic)
  • Ash %
  • Less than 1%
  • Components
  • Rubber strip only, insert available upon request
  • Hardness
  • 655 Shore A
  • Density
  • 1.35 Gram per cubic centimeter(g/cm3)
  • Nitrogen Content (%)
  • Below 0.5%
  • Material
  • Rubber
  • Tolerance
  • 2 mm
  • Temperature Resistance
  • -30C to +70C
  • Product Type
  • Strip Seal
  • Surface Finish
  • Smooth
  • Service Life
  • Designed for long-term service, typically 10+ years
  • Load Bearing Capacity
  • Suitable for vehicular bridges
  • Oil Resistance
  • Moderate (depends on formulation)
  • Edge Reinforcement
  • Steel edge beam compatible design
  • Shape
  • Rectangular seal with bulbous base
  • Installation
  • Press-fit into steel edge beams, adhesive compatible
  • UV Resistance
  • Excellent
  • Chemical Resistance
  • Resistant to road salts and mild acids
  • Abrasion Resistance
  • High
  • Elongation at Break
  • >350%



About Strip Seal



Pick Yours from our outstanding range of Strip Seals, the trending solution for bridge expansion joint sealing in India. This gilt-edged rectangular seal features a bulbous base for easy press-fit installation into steel edge beams; it's adhesive compatible, ensuring a lasting bond. Designed for an eminent service life of 10+ years, our product boasts excellent UV, abrasion, and chemical resistance plus adaptability for vehicular bridges. Advance Purchase options offer standard and customizable sizes, delivering industry-leading durability and performance for bridge maintenance projects.

Plant Application and Installation Sites

Our Strip Seal is predominantly applied in the infrastructure, highway, and bridge construction sectors, ideal for expansion joint sealing at the joints of vehicular bridges. The application method involves a straightforward press-fit technique into compatible steel edge beams, minimizing labor and equipment requirements. The Strip Seal can be deployed onsite at bridge decks, flyovers, and expansion ramps, delivering optimal sealing and structural integrity even under heavy traffic conditions.


Sample Policy, Payment Terms & Certifications

We provide Strip Seal samples for client evaluation before dispatching large orders. Upon confirmation, products are shipped according to your specifications, with secure payment terms-advance purchase or net banking accepted. Our listed prices are competitive, reflecting our outstanding quality and industry compliance. Each strip seal is certified for ASTM-compliant flame resistance and undergoes stringent inspection, ensuring you receive eminent quality with every order shipped. Speak to our team to request detailed certifications or discuss tailored pricing.


FAQ's of Strip Seal:


Q: How is the Strip Seal installed at bridge expansion joints?

A: The Strip Seal is press-fitted into pre-prepared steel edge beams. It is compatible with adhesives, providing enhanced bonding when required, ensuring optimal expansion joint sealing and stability.

Q: What benefits does the Strip Seal offer for vehicular bridge applications?

A: Our Strip Seal provides excellent UV, abrasion, and chemical resistance, long-term durability, and a high compression ratio for accommodating joint movement-making it ideal for heavy-load vehicular bridges.

Q: What process should I follow for advance purchase and sample requests?

A: You may request a sample for quality assessment before placing an order. For bulk orders, our advance purchase policy ensures timely dispatching and availability of standard or custom sizes.

Q: Where are these Strip Seals commonly used?

A: They are predominantly used for sealing expansion joints in bridges, flyovers, and highways, ensuring watertight and flexible joint coverage in demanding infrastructure projects.

Q: When can I expect shipment after ordering?

A: Shipment timelines depend on the order quantity and customization. In-stock standard sizes are shipped promptly, while custom specifications are dispatched as per the agreed schedule.

Q: What certifications do the Strip Seals meet?

A: Our Strip Seals comply with ASTM flame resistance standards and undergo rigorous quality control to verify performance, material composition, and dimensional accuracy before shipping.
