Send InquirySlurry Rubber Hose 200NB 20Bar
Price 5800.0 INR/ Meter
MOQ : 1 Meter
Slurry Rubber Hose 200NB 20Bar Specification
- Shape
- Round
- Hardness
- Medium
- Usage
- Industrial
- Material
- Rubber
- Size
- Standard
- Inside Diameter
- 690 Millimeter (mm)
- Color
- Black
- Warranty
- Yes
About Slurry Rubber Hose 200NB 20Bar
A Slurry Rubber Hose 200NB 20 Bar is a heavy-duty, abrasion-resistant hose designed to handle slurry, mud, sand, and other abrasive mixtures, especially in industries like mining, dredging, cement, and steel plants.
Specification Breakdown:
| Term | Meaning |
|---|---|
| 200NB | Nominal Bore: 200 mm (8 inches) inner diameter |
| 20 Bar | Working pressure: 20 bar ( 290 psi) |
| Slurry Rubber Hose | Designed to carry abrasive slurry materials |
Technical Specifications (Typical):
| Parameter | Details |
|---|---|
| Inner Diameter (ID) | 200 mm (8") |
| Outer Diameter (OD) | Approx. 250280 mm (depends on build) |
| Length | Standard: 3 m / 6 m / custom |
| Working Pressure | 20 bar |
| Bursting Pressure | Minimum 60 bar |
| Inner Lining | NR/SBR/NR-Butadiene abrasion resistant |
| Reinforcement | Multiple textile plies + steel wire helix |
| Outer Cover | SBR/EPDM ozone, weather resistant |
| Ends | Flanged (MS/SS), rubber cuffs, or plain |
| Temperature Range | -20C to +80C |
Key Features:
-
Heavy-duty rubber liner resists abrasion from slurry particles
-
Steel wire reinforcement for vacuum or pressure use
-
Weather, ozone, and UV resistant outer layer
-
Flexible, even at large diameters
-
Available with anti-static and flame-resistant options
Common Applications:
-
Slurry and tailing transport in mining
-
Sand and dredging
-
Cement, fly ash, and concrete transfer
-
Hydraulic fill and ash handling systems
-
Pulp and paper industries
End Fittings Options:
-
Fixed or swivel MS/SS flanges (ANSI/DIN)
-
Built-in rubber flanges
-
Plain end for clamping or coupling
-
Camlock or quick couplings (custom)
Would you like:
-
A datasheet or performance curve for this hose?
-
Material comparison for different slurry media?
-
Help sourcing a manufacturer or supplier?
Let me know your media type (e.g., sand, ash, slurry), hose length, and if you need any fittings I can help you finalize the ideal hose setup.
Superior Construction for Tough Environments
Engineered with premium medium-hardness rubber, this industrial hose is designed to withstand the stresses of abrasive slurry transfer. Its durability and resistance to wear make it suitable for demanding environments, such as mines and construction sites, offering long-lasting service life even under continuous use.
Versatility and Reliable Performance
The hose's 200NB diameter and 20Bar pressure capacity accommodate a wide array of industrial applications. Whether you need to move slurry, chemicals, or other materials, this rubber hose delivers consistent flow and performance. Its round shape and flexible nature allow for ease in installation and operation.
FAQ's of Slurry Rubber Hose 200NB 20Bar:
Q: How is the Slurry Rubber Hose 200NB 20Bar typically used in industrial settings?
A: This hose is primarily used to transport abrasive slurries, liquids, or semi-solids in industries such as mining, construction, and chemical processing, where robust and flexible hose solutions are necessary.Q: What are the main benefits of using a medium hardness rubber hose with a 690 mm inside diameter?
A: A medium hardness hose provides an ideal balance between flexibility and resistance to abrasion, while the large 690 mm diameter ensures efficient high-volume material transfer, improving operational productivity.Q: Where can I purchase or source this Slurry Rubber Hose in India?
A: You can obtain this hose from a wide network in India, including dealers, fabricators, manufacturers, retailers, suppliers, traders, and wholesalers specializing in industrial products.Q: When should this hose be chosen over alternatives for slurry transfer?
A: Select this hose when your application involves the movement of abrasive or high-volume slurries under pressure, particularly when durability, size, and flexibility are essential requirements.Q: What is the manufacturing process behind this industrial rubber hose?
A: The hose is produced using a multi-layer process, combining high-grade rubber and reinforcement materials to achieve the required strength, flexibility, and resistance to industrial abrasives.Q: How does the 20Bar pressure rating enhance safety and operational efficiency?
A: The 20Bar rating ensures that the hose can handle high-pressure slurry transfer reliably without risk of bursting, contributing to safer working conditions and uninterrupted process flow.Q: Is there any warranty provided with this hose, and what does it cover?
A: Yes, the hose is supplied with a warranty. The warranty generally covers material and manufacturing defects, offering assurance of quality and reliable support post-purchase.
