Flexible Rubber Hose

Name: Flexible Rubber Hose
Brand: SANDHYA ENTERPRISES
Price: 6325.0 INR
Availability: InStock

Price 6325.0 INR/ Meter

Get a Price/Quote

MOQ : 1 Meter

Flexible Rubber Hose Specification

Connection Type
Flanged / Threaded / Plain End

Shape
Round

Reinforcement
High tensile synthetic textile

Medium
Air, Water, Oil, Chemicals

Hardness
655 Shore A

Cover
Black, smooth, synthetic rubber

Material
Flexible Synthetic Rubber

Temperature
-40C to +100C

Pressure
1.0 MPa to 2.5 MPa

Inside Diameter
10 mm to 100 mm

Outside Diameter
18 mm to 110 mm

Abrasion Resistance
Excellent

Length
1 meter to 20 meters

End Fittings
Available as per requirement

Application
Industrial, Hydraulic, Pneumatic Systems

Surface Finish
Smooth or Wrapped

Burst Pressure
Up to 3.5 MPa

Flexibility Grade
High

Color
Black

UV Resistance
Yes

About Flexible Rubber Hose

Absolutely! Heres a full overview of a Flexible Rubber Hose, commonly used across many industries for transferring fluids, air, gas, or chemicals.

Flexible Rubber Hose General Overview

Key Features

High flexibility
Pressure-resistant
Abrasion and weather resistant
Vibration dampening
Available in various rubber compounds for different media (air, water, oil, steam, etc.)

Common Materials

Material	Used For
NR (Natural Rubber)	Air, water, low-pressure liquids
EPDM (Ethylene Propylene)	Hot water, steam, weather-resistance
NBR (Nitrile)	Oil, fuel, grease
SBR (Styrene-Butadiene)	General-purpose hoses
Silicone Rubber	High-temperature, food-grade
Viton	Chemicals, high-temp fluids

Typical Specifications

Parameter	Range
Inner Diameter (ID)	6 mm to 300 mm (" to 12")
Length	Standard 10 m / 20 m / 50 m coils
Pressure Rating	From 5 bar to 50+ bar (varies by type)
Temperature Range	-40C to +150C or higher
Reinforcement	Textile braid, steel wire, or spiral
Cover Finish	Smooth or wrapped (textured)

Packing Details

Hose Size (ID)	Coil Length	Packing
1" (25 mm)	50 m or 100 m	Rolled coils, wrapped with film or bags
1" 4"	20 m or 30 m	Rolled coils or straight lengths, strapped
4"	1015 m	Folded or straight lengths, palletized

Packaging Types:

Shrink-wrapped coils
Woven sacks for export
Wooden pallets for heavy-duty hoses
Labeled with size, pressure, material, and batch code

Applications

Water suction/discharge
Air compressor lines
Fuel transfer
Steam lines
Food and beverage processing (FDA-grade rubber)
Hydraulic return or suction lines

If you're looking for a specific type (e.g., oil-resistant hose, food-grade hose, high-temp steam hose), I can help you narrow it down or provide a specification sheet template. Let me know what you're using it for!

Superior Construction and Versatile Applications

This flexible rubber hose is engineered for tough industrial, hydraulic, and pneumatic environments. Its high tensile synthetic textile reinforcement paired with abrasion-resistant cover ensures reliable performance and extended service life. Suitable for conveying air, water, oil, and chemicals, it caters to a wide range of sectors, including manufacturing, fabrication, and supply chain operations.

Customizable for Every Requirement

Available in lengths from 1 to 20 meters and inside diameters from 10 to 100 mm, this hose can be tailored with flanged, threaded, or plain ends to fit specific systems. With a hardness of 655 Shore A and flexible design, end users can specify fittings to match their operational needs, maximizing compatibility and efficiency.

FAQ's of Flexible Rubber Hose:

Q: How can I select the appropriate length and diameter for my application?

A: Determine your operational requirements, including the required fluid volume and the distance the hose needs to cover. With available lengths from 1 meter up to 20 meters and inside diameters ranging from 10 mm to 100 mm, you can choose a configuration that ensures efficient flow and proper fit for your application.

Q: What benefits does the flexible rubber hose offer over traditional hoses?

A: The hose is made from highly flexible synthetic rubber, offers excellent abrasion and UV resistance, and can withstand harsh industrial environments. Its high flexibility grade, burst pressure of up to 3.5 MPa, and temperature range of -40C to +100C make it suitable for demanding industrial, hydraulic, and pneumatic uses.

Q: Where can I use this flexible rubber hose?

A: This hose is ideal for industrial, hydraulic, and pneumatic systems. It handles air, water, oil, and chemicals across manufacturing plants, fabrication units, and maintenance operations, serving as a durable solution for dealers, suppliers, and end-users across India.

Q: What types of end fittings are available and how are they selected?

A: End fittings such as flanged, threaded, or plain ends are available as per your requirements. Selection depends on the type of equipment you are connecting to, operational pressure, and compatibility. Share your needs with your supplier or fabricator for a tailored solution.

Q: When should the hose be replaced or maintained?

A: Inspect the hose regularly for signs of wear, abrasion, or leakage, especially when used under high pressure or in harsh conditions. Replacement frequency varies depending on application intensity, but periodic checks help maintain system safety and hose longevity.

Q: How does the hose maintain performance in extreme conditions?

A: Engineered with UV-resistant and highly abrasion-resistant synthetic rubber, as well as robust textile reinforcement, the hose sustains flexibility and performance from -40C to +100C. This ensures reliable operation in both indoor and outdoor industrial settings.
