150NB Slurry Rubber Hose

Name: 150NB Slurry Rubber Hose
Brand: SANDHYA ENTERPRISES
Price: 3450.0 INR
Availability: InStock

Price 3450.0 INR/ Meter

Get a Price/Quote

MOQ : 1 Meter

150NB Slurry Rubber Hose Specification

Medium
Air

Hardness
55 to 65 Shore A

Reinforcement
Reinforcement in Slurry Rubber Hose High Tensile Synthetic Fabric / Textile Cords Multiple layers of high-strength synthetic fabric (like nylon, polyester, or rayon cords). Provide tensile strength to withstand internal pressure. Maintain hose shape under suction & discharge. Tyre Cord Plies Similar to those used in truck tyres. Give extra durability and shock resistance under pulsating slurry flow. Steel Wire Helix (Optional / Depending on Duty) Embedded spiral steel wire reinforcement inside the hose wall. Prevents collapse under vacuum/suction. Helps in maintaining flexibility while resisting kinking. Copper Wire / Electrical Bonding Wire (Optional) Sometimes an embedded copper wire is included. Provides electrical continuity, preventing static charge build-up.

Cover
Cover in Slurry Rubber Hose Material Made from synthetic rubber compounds (NR/SBR, EPDM, or blends). Specially formulated to resist abrasion, weather, and ozone. Properties Abrasion Resistance protects against external wear from dragging, handling, or contact with sharp surfaces. Weather & Ozone Resistance prevents cracking and hardening in outdoor use. Water & Oil Resistance (Optional) depending on compound, can resist light oils or chemicals. Appearance / Finish Usually black, smooth or cloth-marked (fabric impression) outer finish. Cloth-marked gives extra anti-slip surface and reduces wear when hoses rub together. Hardness Generally around 50 65 Shore A for flexibility with toughness. Special Features (Optional) Wrapped Finish for extra ruggedness. Color Strip / Branding along the cover for identification (e.g., Sandhyaflex Slurry Rubber Hose 150 NB WP 25 BAR ).

Shape
Round

Connection Type
Connection Types in Slurry Rubber Hose Flanged Ends (Most Common) MS / Carbon Steel Flanges fixed or loose type. As per ASA 150#, DIN, or ANSI drilling standards. Provides tight, bolted joint for high-pressure slurry transfer. Used in dredging, mining, and heavy industrial applications. Built-in Flanges The flange is vulcanized with the hose body. Offers better sealing & strength. Reduces risk of leakage compared to detachable fittings. Soft Cuffed Ends Hose ends left plain (without fittings). Designed for clamping or coupling on site. Mostly used for temporary, low-pressure connections. Quick Coupling / Camlock Ends (Special Cases)

Usage
Uses of Slurry Rubber Hose Mining Industry Transport of ore slurry, mineral concentrates, tailings, and mine waste. Withstands abrasion from sharp particles and high pressure. Dredging & Marine Suction and discharge of sand, gravel, silt, and mud in river dredging, port construction, and land reclamation. Construction & Civil Works Handling of cement slurry, bentonite slurry, and concrete pumping. Used in piling, tunneling, grouting, and bridge foundation work. Steel & Power Plants Conveyance of fly ash slurry, slag slurry, and coal dust-water mixtures. Essential for ash handling systems. Chemical & Fertilizer Plants Transfer of gypsum slurry, lime slurry, phosphates, and chemical by-products. General Industrial & Agricultural Use Mud handling, wastewater with solids, drilling fluids, irrigation slurry. Flexible solution where abrasive, semi-solid, or viscous materials need to be moved.

Material
Rubber

Size
150NB

Temperature
80 Celsius (oC)

Height
175 Millimeter (mm)

Pressure
10 Bar

Product Type
Product Type: Slurry Rubber Hose Category: Industrial Rubber Hose Type: Slurry & Mud Rubber Hose (Heavy Duty) Construction: Tube (Inner Lining) Abrasion-resistant natural/synthetic rubber (NR/SBR blend). Reinforcement Multiple plies of high tensile synthetic fabric/tyre cord with embedded steel wire helix (for pressure & vacuum resistance). Cover (Outer Layer) Synthetic rubber, resistant to abrasion, weather, ozone. Size Range: 25 NB (1") up to 600 NB (24") (Standard size: 150 NB = 6"). Pressure Range: Working pressure 10 25 bar (depending on bore size & reinforcement). Length: Standard 3, 5, 6, 10, 15 meters (custom lengths on request). End Connections: MS/CS Flanges (ASA 150# / DIN / ANSI), built-in flanges, or soft ends. Applications: Dredging sand & mud Mining slurry handling Cement & concrete pumping Fly ash and slag transport Industrial and construction slurries

Inside Diameter
150 Millimeter (mm)

Weight
10 Kilograms (kg)

Outside Diameter
175 Millimeter (mm)

Color
Black

Length
6 Meter (m)

Width
175 Millimeter (mm)

Warranty
6month

150NB Slurry Rubber Hose Trade Information

Minimum Order Quantity
1 Meter

Delivery Time
10 Days

About 150NB Slurry Rubber Hose

Specification of 150 NB Sandhyaflex Slurry Rubber Hose

Parameter	Value / Details
Nominal Size / Bore (ID)	150 NB 150 mm internal diameter ( 6) sandhyaenterprises.co.in+2sandhyaflex.com+2
Length Options	Usually supplied in lengths of 3 m, 5 m, 6 m for 150 mm bore. Max standard length 15 m for smaller sizes. sandhyaenterprises.co.in+2sandhyaflex.com+2
Working Pressure	10 to 25 Bar depending on construction / reinforcement. For 150mm slurry hose, 25 Bar is a common rating. sandhyaenterprises.co.in+2sandhyaflex.com+2
Burst / Proof Pressure	Proof Pressure = 1.5 Working Pressure. Burst / peak pressure can be 3 W.P. in many cases. sandhyaflex.com+2hoseandwares.com+2
Vacuum Rating	Minimum vacuum 500-700 mm Hg for slurry & mud hoses. sandhyaflex.com+1
Temperature Range	Roughly 1 C up to +100 C (some variation depending on rubber blend & reinforcement) sandhyaflex.com+2sandhyaenterprises.co.in+2
Lining / Inner Tube Material	Blend of natural rubber + synthetic rubber (e.g. NR/SBR), made to be high abrasion resistance. sandhyaflex.com+2sandhyaenterprises.co.in+2
Reinforcement	High tensile synthetic textile cords, tyre-cords, often with steel wire helices; sometimes electrical bonding wire embedded between plies for conductivity / static dissipation. sandhyaflex.com+2hoseandwares.com+2
Outer Cover	Black synthetic rubber; resistant to abrasion, weather, ozone etc. Sometimes cloth-marked finish. sandhyaenterprises.co.in+2sandhyaflex.com+2
Hardness	Approx. 50-60 Shore A (for the inner lining / general hose body) in many cases. sandhyaflex.com+1
Thickness	Depends on design: inner lining & cover thickness vary; typical wall thickness (lining + reinforcement + cover) might be in tens of mm (inner lining several mm, reinforcement + cover adding more) for slurry hoses. For 150 NB, thickness might be 10-25 mm depending on pressure & reinforcement. sandhyaenterprises.co.in+2sandhyaflex.co.in+2
End Fittings	Flange ends commonly MS Flange as per ASA 150# (also DIN or ANSI standards), or built-in flanges as required. S

Superior Abrasion and Pressure Resistance

Engineered with high-quality synthetic rubber and multiple reinforcement plies, the 150NB Slurry Rubber Hose withstands severe abrasion, high internal pressures, and harsh weather. This makes it suitable for heavy-duty usage in mining, dredging, and industrial environments where durability is crucial.

Versatile Connections for Various Applications

Choose from flanged ends, built-in flanges, soft-cuffed, or quick-coupling connections to accommodate different installations. The hose's adaptability ensures leak-free joints and robust performance whether used for permanent or temporary operations in mining, construction, or power plants.

Tailored for Efficient Slurry Handling

The hose is specially formulated for handling abrasive, semi-solid, or viscous materials like mineral concentrates, cement slurry, fly ash, and chemical by-products. Its flexibility, toughness, and optional electrical bonding enable safe and efficient transfer in aggressive and critical processes.

FAQ's of 150NB Slurry Rubber Hose:

Q: How does the 150NB Slurry Rubber Hose handle abrasive materials?

A: The hose is constructed from abrasion-resistant synthetic rubber compounds and reinforced with high-tensile textile cords. This design enables it to withstand sharp particles and constant friction, making it ideal for transporting ores, slurry, and other abrasive mixtures.

Q: What connection types are available for this slurry hose?

A: Multiple connection options are provided, including flanged ends (fixed or loose), built-in flanges, soft-cuffed ends, and quick couplings. These allow for secure installations tailored to heavy-duty mining, dredging, and industrial needs.

Q: When should I use a steel wire helix reinforced slurry hose?

A: A steel wire helix is recommended when the hose will be subjected to vacuum or suction, as it prevents collapse while maintaining flexibility. It's particularly useful in dredging and suction applications where high durability and kink resistance are crucial.

Q: Where is this hose typically used?

A: The 150NB Slurry Rubber Hose is widely used in mining (for ore slurry and tailings), marine dredging, construction projects (pumping concrete, bentonite), steel and power plants (fly ash slurry), chemical and fertilizer applications, as well as for irrigation and general industrial mud handling.

Q: What benefits does the hose's outer cover provide in outdoor environments?

A: The smooth or cloth-marked outer cover is made from weather and ozone-resistant synthetic rubber. This ensures the hose doesn't crack or harden during outdoor use, while excellent abrasion resistance protects against wear from dragging, handling, and contact with other surfaces.

Q: How does electrical bonding in the hose prevent static charge build-up?

A: Some hoses are embedded with a copper wire, ensuring electrical continuity along the hose length. This feature dissipates static electricity generated by slurry flow, enhancing safety, especially when transporting flammable or volatile materials.
